Champion Copper Plus 852 Spark Plug RCJ6Y

Plug Type: RCJ6Y
Part Description: Spark Plug
Classification: Champion Copper Plus Small Engine
Grade Type: Standard Replacement
Center Electrode Tip Material: Nickel
Center Electrode Design: Standard
Center Electrode Diameter: 0.094 in
Ground Electrode Quantity: 1
Ground Electrode Material: Nickel Copper Alloy
Ground Electrode Core Material: Nickel
Ground Electrode Tip Material: Nickel
Ground Electrode Tip Design: J-Gap
Gap Style: J-Gap
Pre-Gap Size: 0.025 in (0.64 mm)
Hex Type: Hex
Hex Size: 0.748 in (19.0 mm)
Seat Type: Flat
Reach: 0.375 in
Thread Diameter: 0.551 in (14.0 mm)
Insulator Height: 0.06 in
Insulator Projection: 0.06 in
Installed Height: 1.45 in
Taper Diameter: 0.25 in
Manufacturer Heat Range: 6
Resistor Type: Yes
Electrical Terminal Type: Non-Removable Nut
Washer Included: Yes
Washer Type: Crush
Indexed: No
Prop 65 Regulated: No
